Base Mounted Furniture
SYNERSYS Base Mounted Furniture
Introducing our Laboratory furniture, featuring a Modular Base mounted design. The design stands independently, eliminating the need for extra leg frames and ensuring a sleek aesthetic. With easily accessible service areas, it prioritizes convenience in the laboratory environment. Built for strength, it effortlessly supports heavy loads, guaranteeing robust performance.
Maximizing utility, our furniture offers extensive storage within its modular cabinets, available in versatile combinations to meet diverse needs. An ideal choice for budget-conscious labs, this furniture seamlessly combines affordability with quality. Customizable to individual needs, it offers a practical and adaptable solution for a modern laboratory setup.
01DETAILS
|
Casework: Steel |
- Fully Welded Construction
- Cold Rolled Steel 1.0mm thick construction & notched formed and bent to one rigid carcass - Cabinets Chemically cleaned & degreased - Epoxy powder coating between 50 to 80 microns for good chemical & scratch protection - Double panned door / drawer panel filled with sound deadening core - Door hinges made of heavy duty 304SS knuckle butt hinge - Drawer slide on full extendable telescopic slider - Handles either SS pull type or recessed typed - Toebase lined with PVC coved moulding |
|
Casework: Wooden |
- 18mm thick Solid Plywood
- External Surface Laminated with 0.8mm thick plastic lamination - Internal surface to be laminated with white Polykem or colored PVC - Door/drawer Edging with ABS trim - Door hinges and slides feature soft closing - Handles to be aluminium full grip profile type for full length of drawer / door panel |
|
Worktops |
- Epoxy Resin
- Phenolic Resin - Stainless Steel 306 - Stainless Steel 316 - Ceramic - Polypropylene - Laminated Plywood |
|
Base Cabinet |
Drawers, Doors or combination. Various sizes available (450mm, 750mm, 900mm, 1,000mm etc.) |
|
Services |
- Electrical Sockets and trunking
- Water Sink, faucet or DI Water Outlet - Gas Fixture (N2, Air, He, O2, CO2 etc.) - Data/Telephone point - Drying rack for beakers/test tube - Safety Eye wash - Emergency Shower Station - Dilution tank |
|
Cabinet/Bench Height |
- 750mm (sitting)
- 800mm - 900mm (standard) - 1,000mm (standing) - Special height available |
|
Cabinet Width |
- 450mm (single column)
- 750mm (double column) - 900mm (double column) - 1,000mm (double column) - Other Sizes available |
|
Handle |
- Aluminium Recess handle
- Stainless Steel Wire Pull Handle |
|
Back splash |
- Phenolic (80-100mm height)
- Acrylic Panel (Various height) |
02CONFIGURATION
Casework and Cabinets options examples
Drawer Door Cabinet
Drawer and Door Cabinet combinations provide good mix of storage for small consumables and large accessories
Knee Space
Knee space with apron offers located sitting area for lab users or estate to place equipment like Vacuum pump, Dishwasher etc.
Sink Cabinet
Sink cabinets are critical for washing of lab glasswares and good lab practice for hand rinsing. Under sink provide plentiful space for washing tools
Drawers Cabinet
3 or 4 tiers drawers allow ample compartmentation of various lab tools and consumables and easy organization
Wall Hung Cabinet
Wall-hung cabinets offers efficient and organized workspace. The elevated position optimizes desk space, creating a cleaner and more open lab environment.
Flammable Cabinet
Under counter Flammable cabinet not only provide a safe storage for your flammable liquid but utilise existing bench space minimizing the need for extra floor space
Acid Cabinet
Under counter Acid cabinet is pivotal to a safe and organized lab, also promote clutter-free workspace for preventing accidental corrosive spillage
Shelves
Adjustable shelves available on wall or island bench all the flexibility of lab users to adjust height to suit its needs
